Hyperdrive support for MySQL is now generally available (GA). Hyperdrive , Cloudflare’s database connection pooler for Workers, initially only supported Postgres. Since we announced the beta for MySQL protocol support last year, we have been working on making our MySQL handling as reliable as our Postgres support.
We’ve learned some things from building and running a MySQL connection pooler on Cloudflare’s network. It turns out that the difference between beta and GA is just 20 bug fixes in a trenchcoat. During the beta, our goal was to validate that real-world customer usage hit our production availability target of 99.
99%. We knew there were gaps in our reliability since we track how often client connections from a Worker end in an error related to Hyperdrive. In addition, we had feedback from customers in the beta that led to the discovery of a rare and subtle bug in our production environment.
To convey the complexity of this particular bug, we first need to explain how Hyperdrive works. What is Hyperdrive? Hyperdrive is a distributed database connection pooler that connects Cloudflare Workers to SQL databases.
Hyperdrive holds warm SQL connections open on our global network and shares these connections across many Worker requests. In addition to connection pooling, Hyperdrive can also cache common queries in our global CDN cache, reducing latency and load on the origin database. Establishing a connection to a SQL database is expensive, taking a minimum of five network round trips.
On a serverless compute platform like Workers, establishing a connection for each request would be impractical, both because of the amount of latency added to each request, but also because a large number of open connections can incur high per-connection resource costs. While MySQL fares better here than Postgres since MySQL doesn’t use an entire OS process per connection, a typical deployment can still run into resource issues with a large number of connections.
For more details, see our blog post introducing Hyperdrive. A journey to stability Some of the issues we ran into were small and easy to fix once reported. One of the first problems reported in the beta was that emojis written to the database were not being correctly returned.
This was a bug related to character set encoding. Hyperdrive negotiates the encoding for the connection in the startup handshake and we negotiate utf8 as the encoding. As it turns out, utf8 is a deprecated alias for utf8mb3 which is not all of UTF-8: it only supports 1-3 bytes per Unicode code point, while full UTF-8 has a max of 4 bytes per code point.
To get all of UTF-8, we needed to change our handshake to use utf8mb4 , which fixed the emoji issue. Another encoding-related bug occurred when we added connection cleanup via COM_RESET_CONNECTION . This is a lightweight MySQL command to clear any session state in a given connection, which is exactly what Hyperdrive needs to ensure that no session-level state leaks between checkouts.
But adding this connection cleanup step caused encoding issues once again! It turns out that COM_RESET_CONNECTION does not reset the connection state to the character set encoding we negotiated at connection startup; it instead resets the connection to the server default. This means that after negotiating utf8mb4 on a MySQL server instance that defaults to latin1 , once we run COM_RESET_CONNECTION, our connection now has an encoding of latin1 .
The fix is to always run a command setting the encoding to utf8mb4 after a connection reset. A hard-to-find bug During the beta, our highest-volume MySQL customer reported a small but consistent rate of empty query responses for which a non-empty response was always expected. We started the investigation by combing through all of our telemetry and understanding the user’s logic.
Then we also increased the trace rate for this Hyperdrive instance, hoping to see the execution flow of this bug. We searched for network issues that could explain the issue — but nothing seemed to account for this behavior. This error occurred about 0.
001% of the time, which made it very hard to find relevant end-to-end execution traces. But we did have one clue: the bug only occurred on Hyperdrive instances with caching enabled. This made us suspect an issue with Hyperdrive’s MySQL caching.
Hyperdrive caching To understand Hyperdrive's caching, we first need to talk about Hyperdrive's topology and how it interacts with the CDN cache. Every Hyperdrive instance has a split architecture with two nodes: a Client and an Endpoint. The Client node runs on the same machine as the user’s Worker, handles local caching (if enabled), and forwards queries to the Endpoint if needed.
The Endpoint node holds the connection pool and is placed in the data center closest to the origin database. Each node uses the Cloudflare CDN cache local to the data center it is running in. Importantly, this means that if the two nodes are running in the same data center, they will share a cache.
Sharing the cache between Client and Endpoint is generally good for performance. We use a hash of the contents of the query’s wire messages with some normalization and store the result bytes in the cache. If a Hyperdrive Client running in the same data center as its Endpoint receives a request, and that Endpoint has recently cached the results of the same query, the Client can serve the response directly from the shared data center cache.
To work correctly, this scheme requires that the same bytes are cached for the same response, whether stored by the Client or the Endpoint. MySQL client/server protocol Since we couldn’t get a direct trace of the issue, we decided to spend time looking at the MySQL client / server protocol . Perhaps we had an assumption about Postgres’ protocol built into our MySQL handling that was causing these issues.
The protocol describes how a MySQL client communicates with a MySQL server.
